Eaton Tripp Lite U444-006-MDP USB-C to Mini DisplayPort Active Adapter Cable (M/M), 4K 60 Hz, Black, 6' (1.8 m)

Eaton Tripp Lite U444-006-MDP USB-C to Mini DisplayPort Active Adapter Cable (M/M), 4K 60 Hz, Black, 6' (1.8 m)

Eaton Tripp Lite U444-006-MDP USB-C to Mini DisplayPort Active Adapter Cable (M/M), 4K 60 Hz, Black, 6' (1.8 m)
U444-006-MDP | TC-U444006MD
Please sign in to view pricing and availability and to add to cart.
Product Overview
The U444-006-MDP USB 3.1 Gen 1 USB-C to Mini DisplayPort 4K Adapter Cable (M/M) helps you transmit digital audio and 4K video from your tablet, laptop, Chromebook, MacBook, smartphone or PC to an mDP-enabled monitor or projector. It's an ideal tool for giving video presentations in conference rooms and classrooms, editing multiple documents on a larger screen, or streaming video for digital signage in crystal-clear 4K.
With a source device that also supports USB DisplayPort Alternate Mode, you can extend 4K video from your primary display to another, duplicate the same video on both displays, or change the second display to your primary. By connecting to an existing mDP display, you'll save the clutter of adding more cables and adapters.
The plug-and-play U444-006-MDP requires no software, drivers or external power. Connect the reversible USB-C plug to your source device's USB-C or Thunderbolt 3 port. The fumble-free USB-C plug connects in either direction to ensure fast, easy connection every time. Then, connect the mDP plug to your display.
This six-foot cable supports UHD video resolutions up to 3840 x 2160 (4K x 2K) at 60 Hz, 36-bit Deep Color (12 bits per channel) and per-lane transfer rates of 5.4 Gbps (HBR2), 2.7 Gbps (HBR) and 1.62 Gbps (RBR). It also supports USB 3.1 Gen 1 data transfer rates up to 5 Gbps. Foil and braid shielding protects against EMI/RFI line noise that can distort or destroy data.
Main Features
- USB-C to Mini DisplayPort Adapter Cable
- Supports 4K UHD Video at 60 Hz
- Compatible with USB-C and Thunderbolt 3
- Supports USB 3.1 Gen 1 data transfer
- Reversible USB-C Connector for easy use
- Gold-Plated Connectors for maximum conductivity
- Foil and braid shielding against EMI/RFI
- Plug-and-play, no software required
- 6' durable PVC jacket cable
- Backward compatible with non-4K displays
General Information
Specifications
ADI Part Number TC-U444006MD Brand Name Eaton Tripp Lite Connector Gender Male Manufacturer Eaton Manufacturer Part Number U444-006-MDP Packaged Quantity 1 Product Model U444-006-MDP Product Name U444-006-MDP Mini DisplayPort/USB Audio/Video Cable Product Type A/V Cable Weight 0.18lb
Cable Type Mini DisplayPort, USB Connector on First End Mini DisplayPort, Mini DisplayPort 1.2 Digital Audio/Video Connector on Second End USB 3.1 Type C Connector Plating Gold Contact Plating Gold Device Supported Chromebook, MacBook, Monitor, Notebook, Projector, Smartphone, Tablet Shielding Yes
Connector Type USB C (MALE)
Data Transfer Rate 5.4 Gbit/s
Cable Length 6' Color Black Material PVC
Limited Warranty 3-Year
Country of Origin VN Environmentally Friendly Yes Features EMI/RF Protection, Reversible, Strain Relief Package Contents - U444-006-MDP USB 3.1 Gen 1 USB-C to Mini DisplayPort 4K Adapter Cable (M/M), 6 ft.
