TRENDnet TEG-30262 24-Port Gigabit Switch with x 10G SFP+ Slots
TRENDnet TEG-30262 24-Port Gigabit Switch with x 10G SFP+ Slots
TRENDnet TEG-30262 24-Port Gigabit Switch with x 10G SFP+ Slots
TEG-30262 | TQ-TEG30262
Please sign in to view pricing and availability and to add to cart.
Product Overview
TRENDnet's 24-Port Gigabit Switch with 2 x 10G SFP+ Slots, model TEG-30262, provides high bandwidth performance, ease of use, and reliability, all while reducing power consumption by up to 70%*. This 10G SFP switch offers two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. With a sturdy metal housing and included rackmount brackets, the 10G SFP switch is well-suited for 19" 1U rack installations. 10G SFP+ Switch Offers two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. Fanless Fanless design lowers energy consumption and eliminates operating noise. Rackmount Design With a sturdy metal housing and included rackmount brackets, this 10G SFP switch is well-suited for 19" 1U rack installations. PACKAGE CONTENTS TEG-30262 Quick Installation Guide Rackmount kit Power cord (1.8m/6 ft.)
Main Features
- 24 x Gigabit ports
- 2 x 10G SFP+ slots
- 88Gbps switching capacity
- 1U rack mountable (brackets included)
- Fanless Design
- 3 Year TRENDnet Manufacturer's Warranty
- Lifetime Warranty
General Information
Specifications
ADI Part Number TQ-TEG30262 Brand Name TRENDnet Manufacturer TRENDnet Manufacturer Part Number TEG-30262 Packaged Quantity 1 Product Model TEG-30262 Product Name 24-port Gigabit Switch with 2x 10G SFP+Slots Product Series TEG Product Type Ethernet Switch Weight 15.84 oz
Media Type Supported Optical Fiber, Twisted Pair Power Consumption 18.90W
Expansion Slot Type SFP+ Number of SFP+ Slots 2 Number of Total Expansion Slots 2 Shared SFP Slot Yes
Connector Type RJ-45 Modular Yes Total Number of Network Ports 24 Uplink Port No
Manageable No
Network Technology 10/100/1000Base-T, 10GBase-X
Ethernet Technology 10 Gigabit Ethernet Layer Supported 2 Networking Standards IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Compatible Rack Unit 1U Depth 12" Form Factor Rack Mount Height 3" Width 4"
Frequency 50 Hz, 60 Hz Input Voltage 110V AC, 220V AC PoE (RJ-45) Port No Power Source Power Supply
Length 1.6" Mount Type Desktop Mount
Limited Warranty Lifetime
Country of Origin CH Environmental Certification CE, ETL, FCC Environmentally Friendly Yes Package Contents Power cord (1.8m/6 ft.), Quick Installation Guide, Rackmount kit, TEG-30262
