TRENDnet TI-BEP200 2-Port Industrial Outdoor Gigabit Active/Passive PoE+ Extender
TI-BEP200|TQ-TIBEP200
TRENDnet TI-BEP200 2-Port Industrial Outdoor Gigabit Active/Passive PoE+ Extender
TI-BEP200|TQ-TIBEP200
TRENDnet
TRENDnet TI-BEP200 2-Port Industrial Outdoor Gigabit Active/Passive PoE+ Extender
TI-BEP200 | TQ-TIBEP200
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
TRENDnet’s 2-Port Industrial Outdoor Gigabit PoE Extender, model TI-BEP200, takes a single PoE (90W) connection and extends it an additional 100 meters (328 ft.) for up to two PoE devices. It auto-detects a PoE (15.4W), PoE (30W), or PoE (60W) signal, and extends it for a total distance of up to 200 meters (656 ft.) from the PoE source. Daisy chain up to 4 units for a total PoE network extension of up to 500 meters (1,640 ft.). This outdoor PoE extender features a single PoE input port, and one PoE and one Passive PoE output ports.
Main Features
- Easy installation
- Extends 100m for a total distance of up to 200m (656 ft.)
- Daisy chain up to 4 units for a total PoE network extension of up to 500m (1,640 ft.)
- Use a single PoE++ connection to extend PoE for up to two devices
- Supports PoE (15.4W), PoE+ (30W), and Passive PoE (24-48V) devices
- Supports single output Passive PoE (24-48V)
- Wide operating temperature range of -40°- 75° C (-40° - 167° F)
- IP67 outdoor weather rated housing
- No external power adapter required
- Built-in True Surge 4kV Protection
General Information
Name: TRENDnet TI-BEP200 2-Port Industrial Outdoor Gigabit Active/Passive PoE+ Extender
Category: TRENDnet, Data Comm & Networking, PoE Devices, PoE Extenders, ADI Pro Rewards
UPC Code: 710931162400
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
ADI Part Number TQ-TIBEP200 Brand Name TRENDnet Manufacturer TRENDnet Manufacturer Part Number TI-BEP200 Product Model TI-BEP200 Product Name 2-Port Industrial Outdoor Gigabit Active/Passive PoE+ Extender Product Type PoE+ Extender Weight 9.38oz
Input Ports 1 x Gigabit PoE++ Output Ports 1 x Gigabit PoE, 1 x Gigabit PoE+
Color Black Depth 2.9" Form Factor Wall Mount Height 1.7" Width 6.6"
Maximum Output Power 30 W Maximum Output Voltage 48 V DC Minimum Output Voltage 24V DC
Mount Type Wall Mount Protection Type Surge Protection
Limited Warranty 3-Year
Certifications & Standards Standards IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab IEEE 802.3af IEEE 802.3at IEEE 802.3bt Certifications CE FCC IEC 61000-4-2 IEC 61000-4-4 IEC 61000-4-5 IEC 60068-2-27 (Shock) IEC 60068-2-32 (Free Fall) IEC 60068-2-6 (Vibration) Country of Origin TW Package Contents - 2-Port Industrial Outdoor Gigabit Active/Passive PoE+ Extender
- Quick Installation Guide
- 3 x IP67 Weather Rated Cable Glands
- Wrench
- Wall Mount Screws
