TRENDnet TI-PG541 5-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch
TRENDnet TI-PG541 5-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch
TRENDnet TI-PG541 5-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch
TI-PG541 | TQ-TIPG541
Please sign in to view pricing and availability and to add to cart.
Product Overview
TRENDnet's TI-PG541 is a reliable IP30 unmanaged PoE+ DIN-rail switch with hardened components rated for extreme industrial environments. It offers four Gigabit PoE+ ports (Ports 1-4, 802.3at), one Gigabit port, one SFP slot, and a full PoE power budget of 120 Watts. Dual redundant power inputs (power adapter sold separately) with overload current protection support zero downtime requirements. An alarm output can be triggered by a primary and/or redundant power failure. Full PoE+ Power Budget Supplies up to 30 Watts of PoE/PoE+ power per port (ports 1-4 802.3at/802.3af) with a 120 Watt PoE power budget Network Ports 5 x Gigabit Ethernet ports (port 1-4 PoE/PoE+) and 1 x SFP slot Integrated DIN-Rail Mount IP30 rated metal enclosure with integrated DIN-rail mounting hardware
Main Features
- 4 x Gigabit PoE+ (802.3at) ports, 1 x Gigabit port, and 1 x Gigabit SFP slot
- 120 W full PoE+ power budget
- 12 Gbps switching capacity
- Hardened IP30 rated metal switch with integrated DIN-Rail mount
- -40 to 70 ºC (-40 to 158 ºF) operating temperature range
- Dual redundant power inputs with overload current protection
- Alarm output triggered by power failure
- Power supply sold separately (models: 48VDC3000 / TI-S24048 / TI-S12048)
- Power supply sold separately (models: TI-S15052, TI-S24052, TI-S12048, TI-S24048, 48VDC3000)
General Information
Specifications
ADI Part Number TQ-TIPG541 Brand Name TRENDnet Manufacturer TRENDnet Manufacturer Part Number TI-PG541 NDAA Compliant Yes Packaged Quantity 1 Product Line TRENDnet Product Model TI-PG541 Product Name 5-port Hardened Industrial Gigabit PoE+ DIN-Rail Switch Product Type Ethernet Switch Weight 24.20lb
Media Type Supported Twisted Pair Power Consumption 130W
Operating Temperature (T-T) -13-158°F
Expansion Slot Type SFP Number of SFP Slots 1 Number of SFP+ Slots 1 Number of Total Expansion Slots 1
Modular No Network (RJ-45) Yes Total Number of Network Ports 6
Manageable No
Network Technology 10/100/1000Base-T, 1000Base-X
Ethernet Technology Gigabit Ethernet Layer Supported 2 Networking Standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Depth 13" Form Factor Rail Mount Height 17" Width 10"
Frequency 50 Hz, 60 Hz Input Voltage 100V AC, 240V AC PoE (RJ-45) Port No PoE Budget 120W Power Source AC Adapter
Length 5.3" Mount Type Desktop Mount
Limited Warranty Lifetime
Features 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 + 1 x Gigabit SFP, DIN rail mountable, PG541, PoE+ (120 W), Switch, TAA Compliant Package Contents - 5-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch
- Quick Installation Guide
- DIN-Rail kit
TAA Compliant Yes
