TRENDnet TI-PGM102 10-Port Industrial Gigabit PoE+ DIN-Rail Switch
TRENDnet TI-PGM102 10-Port Industrial Gigabit PoE+ DIN-Rail Switch
TRENDnet TI-PGM102 10-Port Industrial Gigabit PoE+ DIN-Rail Switch
TI-PGM102 | TQ-TIPGM102
Please sign in to view pricing and availability and to add to cart.
Product Overview
DEVICE INTERFACE: 8 x Gigabit PoE+ Ports; 2 x Gigabit SFP Slots; 6-Pin Removable Terminal Block; DIN-Rail Mount; LED Indicators; Wall Mount; Grounding Point POE+ POWER & SWITCHING CAPACITY: The industrial PoE+ switch is equipped with 20Gbps switching capacity, and a 240W @56V DC PoE power budget supplies up to eight Power over Ethernet devices with PoE+ power. WIDE TEMPERATURE SWITCH: The metal hardened IP30 rated DIN-Rail Gigabit PoE+ switch is equipped with a rugged IP30 rated enclosure and designed to withstand a wide temperature range 20° - 65°C (-4° - 149°F) for harsh environments. DIN-RAIL & WALL MOUNT KIT: This 10-Port Gigabit PoE+ switch comes with an integrated DIN-Rail mount and mounting hardware brackets. REDUNDANT POWER: The 10-port network switch has dual redundant power inputs with overload current protection (power supply sold separately: models:TI-S12048 / 48VDC3000). ALARM RELAY: The DIN-Rail switch alarm output is triggered by power failure of primary and/or redundant power TRENDnet LIFETIME WARRANTY: The TI-PGM102 Industrial Gigabit PoE+ Switch comes with Lifetime TRENDnet Manufacturer WARRANTY. NDAA / TAA compliant (U.S. and Canada only)
Main Features
- 8 x Gigabit PoE+ ports
- 2 x Gigabit SFP slots
- 240W PoE power budget
- 20Gbps switching capacity
- Hardened IP30 rated metal switch
- Includes DIN-Rail and wall mounts
- Wide operating temperature range of -20° - 65°C (-4° - 149°F)
- Redundant power inputs with overload current protection
- Alarm output triggered by power failure
- Power supply sold separately (models: TI-S24048)
General Information
Specifications
ADI Part Number TQ-TIPGM102 Brand Name TRENDnet Manufacturer TRENDnet Manufacturer Part Number TI-PGM102 Product Model TI-PGM102 Product Name 10-Port Industrial Gigabit PoE+ DIN-Rail Switch -20° - 65°C (-4° - 149°F) Product Type Ethernet Switch Weight 2.43lb
Media Type Supported Optical Fiber, Twisted Pair Power Consumption 6.30W
Expansion Slot Type SFP (mini-GBIC) Number of SFP Slots 2 Number of SFP+ Slots 2 Number of Total Expansion Slots 2
Network (RJ-45) Yes Total Number of Network Ports 8
Network Technology 1000Base-FX, 1000Base-T
Ethernet Technology Gigabit Ethernet Layer Supported 2 Networking Standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Depth 6.3" Form Factor DIN Rail, Wall Mount Height 1.8" Material Metal Width 8.3"
Frequency 50 Hz, 60 Hz Plug/Connector Type Terminal Block PoE (RJ-45) Port Yes PoE Budget 240W Power Source AC, DC
Limited Warranty Lifetime
Country of Origin TW Package Contents - 10-Port Industrial Gigabit PoE+ DIN-Rail Switch -20° - 65°C (-4° - 149°F)
- Quick Installation Guide
- Removable Terminal Block
