Electro-Voice by Bosch
Electro-Voice EVF-1122S/96-PIB Loudspeaker, 90x60, PI-Weatherized, Black
EVF-1122S/96-PIB|UV-EVF12SPIB
Electro-Voice by Bosch
Electro-Voice EVF-1122S/96-PIB Loudspeaker, 90x60, PI-Weatherized, Black
EVF-1122S/96-PIB|UV-EVF12SPIB
Electro-Voice by Bosch
Electro-Voice EVF-1122S/96-PIB Loudspeaker, 90x60, PI-Weatherized, Black
EVF-1122S/96-PIB | UV-EVF12SPIB
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Two-way, high-power full-range system for active or passive operation with an asymmetric CD-horn.
Main Features
- 12" Low Frequency transducer using FEA optimized woofer
- 2" Titanium compression driver with 1.4"-throat diameter
- Rotatable 12"x12" CD horn
- Very linear frequency response from 56 Hz to 20 kHz, max. deviation from linearity +/- 2 dB
- Advanced 4th Order Crossover 24 dB octave Slope with HF protection
- Integrated crossover with an acoustic crossover frequency of 1450 Hz
- Dynamic protection circuit for independent protection of both ways against thermal overload
- Switchable bi-amp or passive operation
General Information
Name: Electro-Voice EVF-1122S/96-PIB Loudspeaker, 90x60, PI-Weatherized, Black
Category: Electro-Voice, Pro AV, Commercial Audio, Pro Speakers
UPC Code: 800549698801
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number UV-EVF12SPIB Brand Name Electro-Voice by Bosch Manufacturer The Bosch Group Manufacturer Part Number EVF-1122S/96-PIB Product Name EVF-1122S 96 12" Loudspeaker Product Series EVF Product Type Speaker Weight 63.05lb
Crossover Type 2-way Impedance 8 ohms Sensitivity 131dB Speaker Size 12"
Maximum Frequency Response 19 kHz Minimum Frequency Response 58Hz RMS Output Power 500W
Sound Emission 2 dB|24 dB
Color Black Depth 16.27" Height 30.3" Material Titanium Size 12" Width 16"
Diameter 12"
