Electro-Voice U30:1 m-US Mixer Alifier, 30W Channel
Electro-Voice U30:1 m-US Mixer Alifier, 30W Channel

Electro-Voice U30:1 m-US Mixer Alifier, 30W Channel
U30:1M-US | UV-U301MUS
Please sign in to view pricing and availability and to add to cart.
Product Overview
Introducing the U30;1M, a 30W mixer amplifier designed to cater to the demands of small to mediumsized installations, where paramount considerations include quality, performance and unwavering reliability. This mixer amplifier is ideal for background music and crystal-clear voice announcement applications, making it a perfect fit for diverse environments such as bars, restaurants, retail outlets, educational institutions, houses of worship, museums, galleries, transport hubs and conference centers. Thanks to its compact size, standing just one rack unit high and half rack wide, the U30;1M presents numerous installation possibilities, even in spaceconstrained settings. Included brackets facilitate both single and dual rack-mount configurations, while desktop and under-counter installations are equally viable. When rack-mounted side by side, two amplifiers can seamlessly inhabit a single rack unit, optimizing space utilization and effectively doubling both channel count and output power.
Main Features
- Versatile inputs - 4 inputs, 2 mic/line options with phantom power support
- Full power output supporting 4 ohms, 8 ohms, 70V and 100V
- EMG override input, ensuring critical messages are heard clearly
- Contact override with 2-tone chime for attention-grabbing alerts
- 70 Hz and 120 Hz high-pass filters to customize audio output and eliminate unwanted low-frequency noise
- Space-saving compact ½ rack design, providing versatility without compromising performance
- VOX Ducking that automatically adjusts background music volume for clear voice communication
- Remote activation of standby mode with Remote OFF (Stand by), enhancing energy efficiency
General Information
Specifications
ADI Part Number UV-U301MUS Brand Name Electro-Voice by Bosch Manufacturer Part Number U30:1M-US Product Name U30:1M Mixer Amplifier 30W, 1 channel Product Type Mixer Amplifier
Impedance 4 ohms|8 ohms
Maximum Frequency Response 22 kHz Minimum Frequency Response 70 Hz RMS Output Power 30W
Operating Power Consumption 6W
Color Traffic Black Depth 8.57" Height 1.74" Width 8.6"
Input Voltage 100-240V AC
