Electro-Voice by Bosch
Electro-Voice ZX1I-100T 8" 2-Way Weather-Resistant Passive Loudspeaker with 100W Transformer, White
ZX1I-100T|UV-ZX1I1TW
Electro-Voice by Bosch
Electro-Voice ZX1I-100T 8" 2-Way Weather-Resistant Passive Loudspeaker with 100W Transformer, White
ZX1I-100T|UV-ZX1I1TW
Electro-Voice by Bosch
Electro-Voice ZX1I-100T 8" 2-Way Weather-Resistant Passive Loudspeaker with 100W Transformer, White
ZX1I-100T | UV-ZX1I1TW
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Weatherized Speaker System with EV DH2005 hi-frequency compression driver. 8" Two-Way, 100x100 coverage pattern. Includes QuickSAM mount bracket and 4-Pole phoenix connector. Includes transformer for 70/100v operation at 6.5, 12.5, 25, 50, 100 watts. White high impact polymer cabinet.
Main Features
- For indoor / outdoor sound reinforcement
- 8" Woofer, 1.25" Titanium HF driver
- Internal crossover and 100W transformer
- ASC Technology prevents LF saturation
- 60 Hz To 20 kHz frequency response
- 100 x 100° Coverage pattern
- Weather-resistant design
- 4-Pin Euroblock connector
- Heavy-duty strong-arm mounting bracket
- ABS Resin cabinet with 2-layer grille
General Information
Name: Electro-Voice ZX1I-100T 8" 2-Way Weather-Resistant Passive Loudspeaker with 100W Transformer, White
Category: Electro-Voice, Pro AV, Commercial Audio, Pro Speakers
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number UV-ZX1I1TW Brand Name Electro-Voice by Bosch Manufacturer Part Number F.01U.265.580 Product Model ZX1I-100TW Product Name Electro-Voice ZX1i-100T 8" 2-Way Weather-Resistant Passive Loudspeaker with 100W Transformer (White) Product Series ZX1i-100T Product Type Passive Speaker Weight 18.5lb
Crossover Type 2-way Impedance 8 ohms Sensitivity 92dB
Maximum Frequency Response 18 kHz Minimum Frequency Response 60Hz RMS Output Power 200W Speaker Configuration 2-Way
Color White Depth 10" Enclosure Type Bass-Reflex Loudspeaker Height 18" Width 11"
Limited Warranty 5-Year
Package Contents Electro-Voice ZX1i-100T 8" 2-Way Weather-Resistant Passive Loudspeaker with 100W Transformer (White), Limited 5-Year Manufacturer Warranty, QuickSAM Strong-Arm Mounting Bracket
