LILIN NAV24108B-10X12TB LILIN NAV24108B Navigator 108-Channel Recorder, 120TB, License Required
LILIN NAV24108B-10X12TB LILIN NAV24108B Navigator 108-Channel Recorder, 120TB, License Required
LILIN NAV24108B-10X12TB LILIN NAV24108B Navigator 108-Channel Recorder, 120TB, License Required
NAV24108B-10X12TB | WC-2418B1012
Please sign in to view pricing and availability and to add to cart.
Product Overview
LILIN NAV24108B 108-channels recorder supports LILIN IP cameras, PTZ dome IP cameras, DVRs, and NVRs. The recorder features up to 108-channels 1080P/3M/4M/5M/8M/12M Network streaming, recording. The recorder is equipped with hardware RAID.
NAV24108B is capable of continuous and schedule recordings. Supports alarm detections including motion, alarm, audio, IVS, and ANPR (Optional) for triggering various alarm outputs. NAV24108B also support simultaneous playback for 36-ch, 2 monitors support, camera groupings, authentication, two-way audio, and dual-streaming provide extra flexibilities for the video management system.
Main Features
- Up to 108 channels 1080P/3M/4M/5M/8M/12M Network streaming, recording
- Support up to 24 × Hot-swap 3.5 Inch SATA HDD (recording)
- 4U dimension for rackmount cabinet
- built-in 1 × 500GB 2.5 Inch SATA SSD (OS)
- Support failover up to 36 channel per server
- 2 monitors support up to 36 channels in total (480P 15fps)
- Support multi-channels synchronized playback (remote or local)
- Support Fisheye camera dewarping
- Redundant Power Supply
- LSI SAS 9361-8i RAID
General Information
Specifications
ADI Part Number WC-2418B1012 Brand Name Merit LILIN Manufacturer Part Number NAV24108B-10X12TB NDAA Compliant Yes Product Series NAV
Connectivity Technology Wired Storage Capacity 120TB Video Formats H.264, H.265, MJPEG
RAID Levels RAID 0, RAID 1, RAID 5, RAID 6
Remote Management Yes
Hard Drive Capacity 120TB
Maximum Resolution 3264 x 2448
ADI Cloud Storage Eligible Yes TAA Compliant Yes
