Genesis 31065511D 22/6 Stranded Unshielded Cable, Plenum, CMP, FT6, 500' (152.4 m) Pull Box, Pink
31065511D|WG-31065511D
Genesis 31065511D 22/6 Stranded Unshielded Cable, Plenum, CMP, FT6, 500' (152.4 m) Pull Box, Pink
31065511D|WG-31065511D
Genesis
Genesis 31065511D 22/6 Stranded Unshielded Cable, Plenum, CMP, FT6, 500' (152.4 m) Pull Box, Pink
31065511D | WG-31065511D
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Genesis Unshielded Multiconductor Cables offer a versatile solution for various signal and limited-power transmission applications.
Main Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Low-Smoke PVC insulation
- Plenum PVC jacket
- Durable rip cord for efficient jacket stripping and removal
- Countdown Length Markings for easy tracking of usage and remaining cable
- Rated for 300 Volts
- Rated for -20 °C to 75 °C
- REACH/RoHS Compliant
General Information
Name: Genesis 31065511D 22/6 Stranded Unshielded Cable, Plenum, CMP, FT6, 500' (152.4 m) Pull Box, Pink
Category: Genesis, Wire & Cable, Security & Access Control Cables, Plenum Unshielded Cables
UPC Code: 619172031035
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number WG-31065511D Brand Name Genesis Manufacturer Genesis Cable Manufacturer Part Number 31065511D Packaged Quantity 1 Product Model 31065511D Product Name Control Cable Product Type Access & Security Cable
American Wire Gauge 22AWG Cable Rating Plenum Cable Type Multi-conductor, Multi-pair Device Supported Audio Devices, Low Voltage applications, Security Device Jacket Type Riser Number of Conductors 6 Number of Pairs 3 Shielding No Solid or Stranded Stranded
Cable Length 500' Color Pink Insulation Material LS-PVC Jacket Material LS PVC Material Bare Copper Package Type REELEX Pull Box
Limited Warranty 3-Year
Country of Origin US Environmental Certification RoHS Environmentally Friendly Yes Features Stranded Indoor/Outdoor Indoor
