Genesis 55541004 14/1-Pair Solid Shielded Fire Alarm Cable, NYC Certified, FPLP, 1000' (304.8 m) Reel, Red
55541004|WG-55541004
Genesis 55541004 14/1-Pair Solid Shielded Fire Alarm Cable, NYC Certified, FPLP, 1000' (304.8 m) Reel, Red
55541004|WG-55541004
Genesis
Genesis 55541004 14/1-Pair Solid Shielded Fire Alarm Cable, NYC Certified, FPLP, 1000' (304.8 m) Reel, Red
55541004 | WG-55541004
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Genesis Fire Alarm Cable ensures uninterrupted fire protection. Built to exceed the demands of rigorous New York City fire safety code. UL listed and Made in the USA.
Main Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Fluoropolymer insulation
- Fluoropolymer jacket
- Countdown Length Markings for easy tracking of usage and remaining cable
- Rated for 300 Volts
- Rated for -20 °C to 150 °C
- REACH/RoHS Compliant
General Information
Name: Genesis 55541004 14/1-Pair Solid Shielded Fire Alarm Cable, NYC Certified, FPLP, 1000' (304.8 m) Reel, Red
Category: Genesis, Wire & Cable, Fire & Life Safety Cables, NYC Certified Shielded Cables
UPC Code: 619172027120
Country of Origin: US. Country of origin is subject to change.
Specifications
ADI Part Number WG-55541004 Brand Name Genesis Manufacturer Genesis Cable Manufacturer Part Number 55541004 Packaged Quantity 1 Product Model 55541004 Product Name 55541004 - 14 Awg 1P Sol Shielded Nyc Ll5, Red, 1000 FT. Reel Product Type Fire Alarm Cable
American Wire Gauge 14AWG Cable Rating Plenum Connector on First End Bare Wire Connector on Second End Bare Wire Device Supported Fire Alarm Jacket Material PVDF Material Bare Copper Number of Conductors 2 Number of Pairs 1 Shielding Yes Solid or Stranded Solid
Cable Length 1000' Color Red Insulation Material PVDF Package Type Reel
Limited Warranty 3-Year
Environmental Certification RoHS Indoor/Outdoor Indoor TAA Compliant Yes
