AXIS P5654-E Mk II PTZ IP Camera, HDTV 1080p with 21x Optical Zoom, 4-84.6mm Lens, 60 Hz
02915-001|Z4-02915001
AXIS P5654-E Mk II PTZ IP Camera, HDTV 1080p with 21x Optical Zoom, 4-84.6mm Lens, 60 Hz
02915-001|Z4-02915001
Axis Communications
AXIS P5654-E Mk II PTZ IP Camera, HDTV 1080p with 21x Optical Zoom, 4-84.6mm Lens, 60 Hz
02915-001 | Z4-02915001
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This cost-effective PTZ camera offers great image quality in HDTV 1080p with 21x optical zoom and wide area coverage with 77° field of view. Thanks to Lightfinder 2.0 and Forensic WDR, it provides true colors and great detail in challenging light or near darkness. Including Axis Object Analytics, it can detect and classify people and vehicles- all tailored to specific needs. With IP66, NEMA 4X, and IK10 ratings, this robust and resistant camera can handle temperatures ranging from -30 °C to 50 °C (-22 °F to 122 °F). Furthermore, Axis Edge Vault safeguards your device and protects sensitive information from unauthorized access.
Main Features
- Axis Edge Vault safeguards the device
- HDTV 1080p with 21x optical zoom
- Lightfinder 2.0 and Forensic WDR
- Support for advanced analytics
- Wide 77° field of view
- 21x optical zoom for desired image clarity and maximum capturing convenience
- Full HD recording format for exceptional video quality with maximum productivity
- Infrared night vision type for better usability and increased surveillance efficiency
- Auto camera iris automatically opens or closes the iris to provide an image of the correct exposure
- Varifocal lens type to ensure maximum surveillance dependability and optimal performance
General Information
Name: AXIS P5654-E Mk II PTZ IP Camera, HDTV 1080p with 21x Optical Zoom, 4-84.6mm Lens, 60 Hz
Category: Axis Communications, Video Surveillance, IP Cameras, PTZ Security Cameras
UPC Code: 7331021086272
Country of Origin: MX. Country of origin is subject to change.
Specifications
ADI Part Number Z4-02915001 Brand Name Axis Communications Manufacturer Axis Communications Manufacturer Part Number 02915001 Product Line P Product Model P5654-E Mk II Product Name AXIS P5654-E Mk II 60 Hz Product Series P56 Product Type PTZ cameras Supported Network Protocols IPv6 USGv6|NIST SP500-267 Weight 5.51lb
Aperture f/1.6-4.5 Connectivity Technology Wired Effective Camera Resolution 4MP Field of View Horizontal, Vertical Lens Type Varifocal Maximum Aperture f/4.5 Maximum Frame Rate 60fps Minimum Focal Length 4mm Night Vision Yes Night Vision Type Infrared Optical Zoom 21x Video Formats H.264, H.265, MJPEG, MPEG-4
Wide Dynamic Range Yes
Image Sensor Size 1/2.8" Maximum Video Resolution 1920 x 1080
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -22°F (-30°C) Operating Humidity 0.95
Longest Shutter Speed 2 Second Minimum Illumination 0.01 lux Shortest Shutter Speed 1/66500 Second
Network (RJ-45) Yes
Focal Length 4.0-84.6mm Lens Included Yes Maximum Focal Length 84.60 mm Minimum Aperture f/1.6
Memory Card Supported Yes
Remote Management Yes
Color White Durability Dustproof, Impact Resistant, Shock Resistant, Waterproof Form Factor Dome
Input Voltage 240V AC Maximum Power Consumption 16W Power over Ethernet (PoE) Yes
Diameter 5.9" Mount Type Ceiling Mount
Recording Formats Full HD Storage Type Memory Card
Limited Warranty 5-Year
Certifications CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A Certifications & Standards ONVIF G, ONVIF M, ONVIF S, ONVIF T Environmental Certification IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X Environmentally Friendly Yes Features Auto Tracking, Day/Night, Defog, HTTPS Encryption, Human Detection, Privacy Masking, Vehicle Detection, White Balance, Wide Dynamic Range Impact Protection Rating IK10 Indoor/Outdoor Outdoor Ingress Protection Rating IP66 Package Contents - Camera,
- installation guide,
- smoked dome,
- RJ45 push-pull connector (IP66),
- hard ceiling mount,
- spring clip adapter,
- U-profile adapter pipe
TAA Compliant Yes
