ViewZ VZ-DC24-320 Power Supply, 24V DC, 120V AC|124V DC|230V AC|370V DC, Wall Mount
VZ-DC24-320|ZQ-VZDC24320
ViewZ VZ-DC24-320 Power Supply, 24V DC, 120V AC|124V DC|230V AC|370V DC, Wall Mount
VZ-DC24-320|ZQ-VZDC24320
ViewZ
ViewZ VZ-DC24-320 Power Supply, 24V DC, 120V AC|124V DC|230V AC|370V DC, Wall Mount
VZ-DC24-320 | ZQ-VZDC24320
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The ViewZ VZ-DC24-320 Power Supply offers reliable 24V DC output with a power capacity of 320W. It supports a versatile AC input range from 88 to 264V AC (124 to 370V DC) at 47 to 63Hz frequency. Designed with a sleek 30mm low profile, this wall-mountable unit fits perfectly in 1U installations. Safety features include protections against over voltage, overload, over current, and short circuits. Equipped with an active PFC function, it maintains a power factor above 0.95. The power supply also features conformal coating, a green LED indicator for output status, and is UL/C US listed for safety assurance. Ideal for efficient and secure power needs, get yours today!
Main Features
- AC Input - 88 ~ 264V AC (124 ~ 370V DC), 47 ~ 63Hz
- DC Output - 24V DC / 320 W
- Over Voltage / Overload / Over current/ Short Circuit Protection
- 30mm Low Profile Design for 1U Installation
- Built-in Active PFC function, Power Factor > 0.95
- A Low Profile Enclosed Power Supply with PFC Function
- Conformal Coating and Green LED per Output
- UL/C US listed
General Information
Name: ViewZ VZ-DC24-320 Power Supply, 24V DC, 120V AC|124V DC|230V AC|370V DC, Wall Mount
Category: ViewZ, Batteries & Power Supplies, Power Supplies & Boards, Power Supplies
UPC Code: 856478005685
Country of Origin: TW. Country of origin is subject to change.
Specifications
ADI Part Number ZQ-VZDC24320 Brand Name ViewZ Manufacturer ViewZ Manufacturer Part Number VZ-DC24-320 Product Model VZ-DC24-320 Product Name Output 24V DC / 320W Power Transformer Product Type Step Down Transformer Weight 8.20lb
Output Voltage 24V DC
Color Green Height 13.4" Width 8.3"
Input Voltage 120V AC, 124V DC, 230V AC, 370V DC Maximum Line Current 13.40 A Power Rating 320VA
Limited Warranty 3-Year
Certifications & Standards U.L Listed CUL Listed Compatibility ViewZ Public View Monitors: VZ-PVM-Z2B3 VZ-PVM-Z2W3 VZ-PVM-Z3B3 VZ-PVM-Z3W3 VZ-PVM-Z4B3 VZ-PVM-Z4W3 VZ-PVM-I2B3 VZ-PVM-I2W3 VZ-PVM-I3B3 VZ-PVM-I3W3 VZ-PVM-I4B3 VZ-PVM-I4W3
