Product Overview
These MEGApix IP cameras deliver crystal-clear images at 4MP resolution and real-time 30 fps. The bullet camera features a 2.8mm fixed lens in an IP67-rated, IK10 impact-resistant housing. Added intelligence includes line crossing, perimeter intrusion and video tampering detection. All MEGApix cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.
Main Features
- 4MP 1/3" Image sensor at real-time 30 fps
- 2.8mm Fixed lens
- True Wide Dynamic Range (WDR) for clear images in challenging light
- Simultaneous streaming and multiple codec options for smart bandwidth management
- 164' Smart IR with intelligent camera sync for clear B/W images with no need for external light
- Line crossing video analytics
- Perimeter intrusion video analytics
- Video tampering with scene-change detection video analytics
- Video tampering with video-blur detection video analytics
- Video tampering with abnormal color detection video analytics
General Information
Name: Digital Watchdog DWC-VSBD04BI MEGApix 4MP WDR Bullet IP Camera with Smart IR, 2.8mm Fixed Lens, NDAA Compliant, White
Category: Digital Watchdog, Video Surveillance, IP Cameras, Wireless Cameras, Bullet Cameras
UPC Code: 812226038220
Country of Origin: TW. Country of origin is subject to change.
Specifications
ADI Part Number 6K-VSBD04BI Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWC-VSBD04BI NDAA Compliant Yes Product Line MEGApix Product Model DWC-VSBD04Bi Product Name MEGApix 4MP bullet IP camera with fixed lens and IR Product Series V-Class Product Type Network Camera
Connectivity Technology Wired Effective Camera Resolution 4MP Field of View Horizontal, Vertical Lens Type Fixed Material Aluminum Die-cast Maximum Aperture f/1.6 Maximum Frame Rate 30 fps Minimum Focal Length 2.8 mm Night Vision Yes Night Vision Type Infrared Video Formats H.264, MJPEG
Night Vision Distance 164 ft Wide Dynamic Range Yes
Maximum Video Resolution 1920 x 1080
Maximum Operating Temperature 140°F (60°C) Minimum Operating Temperature -22°F (-30°C) Operating Humidity 0-95% RH (Non-condensing)
Longest Shutter Speed 1/2 Second Minimum Illumination 0.0 lux (B/W)|0.005 lux (color) Shortest Shutter Speed 1/100000 Second
Network (RJ-45) Yes
Focal Length 2.8 mm Lens Included Yes Maximum Focal Length 2.80 mm
Remote Management Yes
Color White Depth 2.8" Durability Weather Resistant Form Factor Bullet Height 8.7" Width 3.2"
Input Voltage 12V DC
Mount Type Ceiling Mount, Wall Mount
Recording Formats 2K Storage Type Memory Card
Limited Warranty 5-Year
Environmental Certification RoHS Environmentally Friendly Yes Features 3D Digital Noise Reduction, Back Light Compensation (BLC), Cross Line Detection, Digital Watermark, Highlight Compensation (HLC), Human Detection, Motion Detection, Privacy Masking, Smart IR, Tamper Detection, Wide Dynamic Range Impact Protection Rating IK10 Ingress Protection Rating IP67
